RVB4300

Spreader

See What We Can Spread


The Revolution™ V-box poly hopper is specifically designed to never collapse. This might seem odd but that is the main reason that poly spreaders don’t last. While we beefed up the construction we added specific tie-down connection points and anti-crush zones. You deserve quality.

Our PATENTED Inverted Vee (NOT NEEDED or AVAILABLE on RVB10 and RVB500) is actually one of the secrets to the success of this V-Box spreader. The design allows the contractor to dial in the specific amount of material that will drop to the auger BASED on the material they are spreading.

The Revolutionary RS Controller offers Constant Drive and Auto Mode that allow customization of the independent auger and spinner and vibrator in maximizing material distribution. In addition, the controller operates key accessories such as pre-wetting systems and lighting.

The chutes are available in 16” short chute and 29” long chute. Easy on/off stainless steel and roto molded chute has a 16” four flute poly spinner to provide you long life and superior spread pattern up to 30’.

Choose a short chute or long chute to go with your RVB spreader (not included) See Spec chart for measurements.

Applications

EXCLUSIVE BENEFITS

9 Models: Fits UTV to Class 7 Trucks

Exclusive Benefits

for V-Box Sno-Way® Spreaders

  • The Revolution™ V-Box family has a roto molded perimeter with ribbed hopper, supported by a custom frame and drive support.
  • The easy on/off stainless steel and roto molded chute has a 16” four flute poly spinner to provide you long life and superior spread pattern up to 30’. Available in 16” short chute or 29” long chute. Choose one to go with your RVB Spreader (chute not included with spreader).
  • RVB 4300 has a .6 horsepower direct drive gear box for the auger and a 1/3 horsepower spinner motor, they are fully enclosed so that water and salt do not penetrate.
  • The inside of the poly hopper walls are designed for maximum flow of the toughest materials to minimize material bridging.
  • One harness supplies all of the power from the battery to the hopper, with a water-tight Duetsch connector and seal to connect them. The harness is plug and play for accessories. No cutting or splicing.
  • Adjustable inverted vee. Adjust the inverted vee system to match the material you want to spread.
  • Optional Wetting System with Filling Station available: RVB4300 accepts up to 6 tanks.
  • RVB4300 has an Automotive E-coat primer and military grade powder coated steel frame and drive support.
PRODUCT HIGHLIGHTS

Patented Products Make All The Difference

The combination of the RS Controller, Patented Inverted Vee (NOT NEEDED or AVAILABLE on RVB10 and RVB500) and the Auger Drive is what makes this Revolution™ RVB Spreader work so well. A contractor has the ability to spread any materials demanded by the client with a consistent pattern at the proper speed and with no loss of valuable material. By dialing in the specific flow of material to the auger and then controlling the auger speed independent of the spinner speed the contractor has ultimate control of every necessary component of the hopper spreader.

VIDEOS
OPTIONS & ACCESSORIES
SPECS & MORE
Model RVB4300
Capacity 4.3 Cubic Yard
Empty Weight 905 lbs.
Overall Length (A) 133"
Body Side Length (B) 110"
Overall Height (C) 57”
Width 52"
Depth 127"
Spinner Motor 12 Volt, 1/3HP
Auger Motor 12 Volt, .6 HP
Spinner 16” Diameter Poly Four Flute
Chute* Easy On/Off 16” Short Chute, 29” Long Chute
Trough and Frame Steel, E Coat, Powder Coat
Vibrator Standard
Second Vibrator Standard
Stainless Steel Inverted Vee Standard
Top Screen Standard
Tie Down Brackets Standard
Vinyl Tarp Optional
Auxiliary Lights Optional
Ratchet Straps Optional
Control RS Digital Control
Wetting System Optional
Recommended Use Class 6 and 7
* Choose a short or long chute for your RVB spreader (not included) Both long and short chute are approximately 30” wide.
  • The Revolution™ V-Box Family has a roto molded perimeter with ribbed hopper, supported by a custom frame and drive support.
  • The easy on/off stainless steel and roto molded chute has a 16" four flute poly spinner to provide you long life and superior spread pattern up to 30'.
  • The 1/2 horsepower direct drive gear box and 1/3 horsepower spinner motor are fully enclosed so that water and salt does not penetrate.
  • The inside of the poly hopper walls are designed for maximum flow of the toughest materials to minimize size material bridging.
  • One harness supplies all of the power from the battery to the hopper, with a water-tight Duetsch connector and seal to connect them. The harness is plug and play for accessories. No cutting or splicing.
  • Adjustable patented inverted vee (NOT NEEDED or AVAILABLE on RVB10 and RVB500). Adjust the inverted vee system to match the material you want to spread.
  • Optional Wetting System with Filling Station available.
RS Controller
RS CONTROL Allows you to adjust auger and spinner speed independently using pinwheels to increase or decrease speed of the auger or spinner

RS CONTROL Has:
  • Push Button to: turn on/off vibrator or vibrators
  • Turn on/off optional light
  • Turn on/off optional wetting system
  • All functions can be controlled in Auto Mode

Spreader Materials

Sodium Chloride

Calcium Chloride

Bagged Ice Melters

Bulk Salt – Wet or Dry

50/50 Salt Sand

Sand – Wet or Dry (** Use vibrator motor kit)

Pea Gravel

Magic Salt
